Module Grow Lights
XD-800W-1M5
800W module grow light for greenhouse, indoor farming and professional cultivation projects.
| Model | XD-800W-1M5 |
|---|---|
| Light Source | Samsung & Osram LED |
| Spectrum | Full spectrum white light + 660nm + 460nm |
| PPF | 2080 umol/s |
| Efficacy | 2.6 umol/J |
| Light Efficacy / Lumen Output | 150 lm/W / 120000 lm |
| Input Power | 800W ±5% |
| Input Voltage / Current | 120V 7.3A; 220V 3.7A; 240V 3.1A; 277V 2.9A |
| Frequency / Power Factor | 50/60Hz / >0.95 |
| Dimming / Control | RJ Connector, 0-10V |
| Lifetime / Light Distribution | L90 > 54,000 hours / 70 x 120° |
| Waterproof Rate / Warranty | IP54 / 5 years warranty |
| Mounting Height | ≥24" (60cm) above canopy |
| Ambient Temperature | -20°C ~ +45°C |
| Thermal Management | Passive |
| Bars / Weight | 2 pcs / 14.2kg |
| Dimensions | 915 x 365 x 75mm |
PDF Catalog Details
TECHNICAL SPECIFICATIONS / PPFD Value / DIMENSIONS / Standard Spectrum
This section displays the original Agrilumia catalog page for this product, including the complete technical specifications, PPFD map, dimensions drawing and standard spectrum.
